ELE® company began to develop market in China since 1996 and built factory in Pudong, Shanghai in 2006.By now ELE® has developed as a global centre of machining and service.
The type is the world’s top wet grinding machine, designed and developed for ultrafine grinding materials of high cleanliness and without metal contamination.
ELE equipment is suitable for various branches of chemical industry. Our engineers with rich experience, our technology integration centre will make best solution for your process.
The High Speed Disperser applies to all kind of liquid to pre-mix,disperse,color matching,etc
High-Efficiency production,hydraulic lifting,frame can turn around flexible.when mixing and dispersing,there is little air suction.it can dissolve the material quickly and particle become finer
Working principle
High Speed Disperser
Hydraulic Lifting High Speed Disperser
Specification
Model/
Paramter
Main Power
(KW)
Rotation speed
(rpm)
Diameter of disc
(mm)
Stroke
(mm＜)
Pump power
(KW＜ )
Weight
(Kg)
Length
(mm＜)
Height
(mm＜)
Centre
Distance(mm)
EBF-4
4
1400
100-200
700
0.75
700
1400
1420
580
EBF-7.5
7.5
1400
200-300
900
0.75
1000
1650
1850
765
EBF-11
11
1400
200-300
900
0.75
1000
1650
1850
765
EBF-15
15
1400
200-300
900
0.75
1000
1800
1850
915
EBF-18.5
18.5
1250
300-400
1200
0.75
1500
1800
2120
1100
EBF-22
22
1250
300-400
1200
0.75
1500
2360
2120
1250
EBF-37
37
1250
300-400
1200
1.1
1800
2520
2120
1400
EBF-45
45
1250
400-500
1500
1.1
1800
2830
2750
1400
EBF-55
55
1250
400-500
1500
1.1
2000
2830
2750
1500
Advantage
1.The machine with this special built-in structure will decrease some unnecessary problems;
Your production will not be influenced by leaking oil
2.The structure of inner oil hydraulic cylinder only need little oil and no leak,stable rise and fall
Hydraulic Lifting High Speed Disperser
