Pneumatic Lifting High Shear Homogenizer

EBR series High shear homogenizer mixer adopt most advanced technology for rotor and stator precise positioning, which is the core technology for emulsifying effect. The whole machine system adopt pneumatic lift style, frequency converter speed adjusting system, easy to operation and maintenance. The bi-direction material absorption system make the best homogenizing effect. This model is widely used in cream, ointments, sauce, flavoring emulsions and pharmaceutic products etc.



Working Principle


Specification

Item: High shearing homogenizer

Power Supply: 380v, 50Hz,three phase ( can be customized)

Capacity: 10L-10000L

Rotation Speed: 0-3000rpm

Speed Adjustment: with inverter(various speed control)

Lifting method: Pneumatic lift

Pneumatic Lifting High Shear Homogenizer

Pneumatic Lifting High Shear Homogenizer


Pneumatic Lifting Homogenizer

Pneumatic Lifting Homogenizer


Features

1.the stator and rotor is after special heat treatment and precision forging

2.the material of the stator and rotor is ss304, 316L stainless steel

3.the rotation part is after dynamic and static balance test, low noise, prolong the service life.

4. the surface is after special treatment, advance the abrasion resistance.

5.claw structure,  two-way suction, linear cutting. good circulation, without dead corner

6.mixing tank is able to achieve heating or cooling, vacuum


Machine details


Advantages

The noise is low, the efficiency is high, running smoothly without a blind spot, 100% through the working cavity.Large processing flow, suitable for industrial continuous production, to deal with the range of viscosity wider.



Application

Biology, pharmacy, food, ink, textile auxiliary, cosmetic lubricating oil and fertilizer etc. solution, gel, suspension or emulsion Juice, soup bases, milk production, mayonnaise, tissue homogenate, shampoo, lotion, emulsion, surfactants, asphalt, oil field chemicals, lubricant, etc.



Data Sheet & Models

Model

Power /KW

suggested capacity/L

Rotation/rpm

Liftingheight  (mm)

Material

EBR-1.1

1.1

<100

3000

600

SUS304/316L

EBR-2.2

2.2

<150

3000

700

SUS304/316L

EBR-4

4

<200

3000

800

SUS304/316L

EBR-7.5

7.5

<500

3000

900

SUS304/316L

EBR-11

11

<800

3000

900

SUS304/316L

EBR-15

15

<1200

1500/3000

900

SUS304/316L

EBR-18.5

18.5

<1800

1500/3000

1100

SUS304/316L

EBR-22

22

<2000

1500/3000

1100

SUS304/316L

EBR-30

30

<2500

1500

1100

SUS304/316L

EBR-37

37

<3000

1500

1600

SUS304/316L

EBR-45

45

<4000

1500

1600

SUS304/316L

EBR-55

55

<5000

1500

1600

SUS304/316L



Professional technical supports & Processing Machines

Our engineers are around 20years rich experience in this area, professional skills and stable processing.

We have lathes, grinder, drilling machine, boring machine, polishing machine, milling machine…etc.

Office


Fine process center


Fine process center

Polishing center


Welding


Gringding




Maintenance & Services

1.Before order, customer can take materials to ourvlab and make test grindings, spot-testing parameters like particle size distribution, obtain reliable data for model selection;

2.We provide you opeatian manual by chinese or English;

3.We offer you Videos for equipment installation and maintenance in both English and Chinese;

4.With three years of spare parts inventory to ensure normal use and make you to be in trouble free;

5.Within 12-months warranty period, we promise to change damaged parts free of charge by air or by sea;

6.After delivery, our professional engineer will offer on-site guidance debugging free of charge, according to different characteristic of materials, to set up the operational parameters of the mill and ensure optimal grinding quality & equipment running status;

7.After the warranty period, we provide maintenance and maintenance service, only charge the cost;

8.Meanwhile, our skillful grinding experts can offer you free professional technical consulting and service.
