Single Stage Inline High Shear Homogenizer Pump

This model with key part of stator and rotor, which is linear cutting, It can disperse, mix and emulsify various kind of liquid with different viscosity by high shearing power. Widely used in production of food, beverage, fragrance, cosmetic, shampoo, asphalt/bitumen emulsion, shampoo.



Working Principle

Has similar work theory with high shear batch emulsifier, which the rotor and stator work together to generate strong shearing power during speedy running to realize mixing, smashing and emulsion. Inline mixer could also be fixed on pipeline to do continuous work.The standard components are pump chamber,rotor and stator. Inline mixer is applied to emulsify and disperse kinds of liquids continuously, transmits low viscosity material and mix powder and liquid.It is widely used in the field of Daily, Beverage, food,  Pharmacy, Chemical industry etc.



Specification

· Power supply: 380v, 50hz, 3ph (voltage can be customized)

· Rotation speed: 0-3000rpm/0-1500rpm

· structure: 6 layers of stator and rotor

· flow:0.5-70m3

· Surface treatment: electro polishing, inner: Ra0.8-1.2um, outerRa3.2um, other part is coated resisteance to chemical corrosion paint

· Single stage Two Layer of precision engieered stator and rotor inside of the chamber

· double end mechanical seal, can design water protector according to requirement

· perfect emulsifying, reach micro-emulsion, suitable for high requirement emulsion

· adopt elastic connection, low noise, prolong the service life

· material: all parts contract with material is ss304 or ss316L stainless steel

· head/lift: 8m

Inline High Shear Homogenizer Pump


High Shear Homogenizer Pump


Machine details


Advantages

1. Time-saving, energy-saving and high efficiency

2. Low noise and stable running

3. Eliminating the differences between the batch production

4. With the function of short distance and low lift transportation, availability for circular process

5. Easy operation and simple maintenance

6. Availability for automatic control


Application

Emulsifying (Liquid to liquid),metal- oxide suspension and water-in-oil or oil-in-water emulsion manufacturing, accelerating reaction speed, improving activator productivity, nano-chemical products producing.


Data Sheet & Models

Model

Power(kw)

Rotation(rpm)

Flow (m3/h)

Entrance

Exit

ELR401/1/6

1.1

2890

1

DN40

DN32

ELR405/1/6

4

2890

4

DN40

DN32

ELR410/1/6

7.5

2890

8

DN50

DN40

ELR415/1/6

11

2890

12

DN65

DN50

ELR420/1/6

15

2890

18

DN65

DN50

ELR425/1/6

18.5

2890

20

DN65

DN50

ELR430/1/6

22

2890

22

DN65

DN50

ELR450/1/6

37

1440

30

DN100

DN80

ELR475/1/6

55

1440

40

DN125

DN100

ELR490/1/6

75

1440

55

DN125

DN100

ELR510/1/6

90

1440

65

DN125

DN100

ELR530/1/6

110

1440

80

DN150

DN125


Professional technical supports & Processing Machines

Our engineers are around 20years rich experience in this area, professional skills and stable processing.

We have lathes, grinder, drilling machine, boring machine, polishing machine, milling machine…etc.

Office


Fine process center


Fine process center

Polishing center


Welding


Gringding



Maintenance & Services

1.Before order, customer can take materials to ourvlab and make test grindings, spot-testing parameters like particle size distribution, obtain reliable data for model selection;

2.We offer you Videos for equipment installation and maintenance in both English and Chinese;

3.With three years of spare parts inventory to ensure normal use and make you to be in trouble free;

4.After delivery, our professional engineer will offer on-site guidance debugging free of charge, according to different characteristic of materials, to set up the operational parameters of the mill and ensure optimal grinding quality & equipment running status;

5.After the warranty period, we provide maintenance and maintenance service, only charge the cost;
